Specifications:
Model | Excavator Size | Weight | Shear Opening |
Wood Cutting Diameter |
(ton) | (kg) | (mm) | (mm) | |
CL190 | 2.5 - 7.5 | 210 | 685 |
250 |
CL260 | 6 - 14 | 360 | 760 | 320 |
CL320 | 12 - 20 | 620 | 1,060 | 400 |
Resources
Basic Tree Shears
Westtech Woodcracker’s versatile range of tree shears are designed for efficient tree management and wood processing. The Woodcracker CL
series provides precise cutting and handling of trees & vegetation. These durable shears enhance the efficiency of forestry & land
clearing operations, making them valuable tools for professionals in the industry.
Features:
- Robust Gripper System - Equipped with a strong gripper and large opening width, the CL series can handle multiple trees and bushes simultaneously.
- Lightweight Construction - The low net weight allows mounting on smaller carrier vehicles, enhancing versatility in different terrains.
- High-Strength Blade - Features a replaceable, high-strength blade that is easy to sharpen and resistant to dirt, ensuring durability and low maintenance.
- Durable Build - Constructed from high-strength Hardox® steel with KTL-primed (cathodic dip-coating) and powder coating for enhanced durability and excellent corrosion protection.
- Optimum attachment angle mounting bracket.
- Well protected hydraulic hose routing throughout the attachment.
- Optional Accumulator - An accumulator option is available for faster processing of weak wood, improving efficiency in certain applications.
- Autospeed Function - The optional Autospeed feature enables faster closing of the cutting unit through a hydraulic regeneration valve which increases harvest performance and reduces fuel consumption.
Options:
- Auto speed valve.
- Accumulator arm.
- Cylinder tilting head +/- 48°
